Fencing Partner
YISHUO®
A - Height : 1800 mm, 2100 mm, 2400 mm, 3000 mm
B - Width : 2750 mm
C - Pale Type : W-profile, D-profile and angle steel
D - Pale Ton : Square top, triple pointed top, single pointed top, round top, round & notch top, etc.
E - Pale Thickness : 15 mm, 20 mm, 25 mm, 30 mm, 3,5 mm
F - Horizontal Rail : angle steel (40 mm x 40 mm x 4 mm,
50 mm x 50 mm x 5 mm, 50 mm x 50 mm x 6 mm)
G - Post : Square post (60 mm x 60 mm, 80 mm x 80 mm,
100 × 100 mm);Customized
H - Connection : fish plate (40 mm x 8 mm x 150 mm)
• Excellent resistance to deformation
High tensile fixings and support base offer maximum resistance to deformation.
• Match up with most surroundings
A wide range of designs and colors are available to perfectly match up with most surroundings.
• Corrosion & rust resistance
Excellent corrosion & rust resistance and weather resistance performance.
• Fast & easy installation
Fast and easy installation and less maintenance.
• Against unauthorized access, vandalism and attack
Providing a higher level of security and excellent protection against unauthorized access, vandalism and attack.
A - Height : 1800 mm, 2100 mm, 2400 mm, 3000 mm
B - Width : 2750 mm
C - Pale Type : W-profile, D-profile and angle steel
D - Pale Ton : Square top, triple pointed top, single pointed top, round top, round & notch top, etc.
E - Pale Thickness : 15 mm, 20 mm, 25 mm, 30 mm, 3,5 mm
F - Horizontal Rail : angle steel (40 mm x 40 mm x 4 mm,
50 mm x 50 mm x 5 mm, 50 mm x 50 mm x 6 mm)
G - Post : Square post (60 mm x 60 mm, 80 mm x 80 mm,
100 × 100 mm);Customized
H - Connection : fish plate (40 mm x 8 mm x 150 mm)
- All panel pales are provided in 17 pieces;
- M8 × 30, M12 × 30 anti-vandal steel or stainless steel bolts are provided;
- All colors are available in RAL;
- Other materials and specifications are available upon request
Materials of Wire Mesh Panel : Q235 steel
Materials of Post : Q235 steel
Materials of Bolts : Stainless Steel or Low Carbon Steel
Surface Treatment : Hot Dipped Galvanized, Powder Coated, PVC Coated.
Color : All RAL Color are available
Process of Manufacturing : Materials---Iron wire---Wire cutting---Welded---Galvanized---Powder coated or other finish.
